AMD Ryzen 5 9600X 3.9 GHz 6-Core AM5 Processor 100-100001405WOF
Overview :
Take your computing experiences to a new level with the AMD Ryzen 5 9600X 3.9 GHz 6-Core AM5 Processor. Featuring 6 cores and 12 threads with 32MB of L3 Cache, this desktop processor quickly loads and multitasks demanding applications.
Designed for socket AM5 motherboards using the powerful Zen 5 4nm architecture, this processor offers exceptional performance. With a base clock speed of 3.9 GHz and a max boost clock speed of 5.4 GHz, the Ryzen 5 9600X delivers the power needed to smoothly handle tasks ranging from content creation to immersive gaming experiences. You can boost performance further by overclocking this unlocked processor. Other features include support for PCIe Gen 5 technology and 5600 MHz ECC DDR5 RAM with compatible motherboards.
This processor has a 65W TDP (Thermal Design Power) and does not include a cooling solution. Integrated Radeon Graphics delivers rich visuals.
Precision Boost 2
AMD Ryzen processors monitor the system’s energy consumption, temperatures, and other factors to automatically raise clock speeds, allowing applications to perform faster.
Precision Boost Overdrive
Precision Boost Overdrive technology takes advantage of your compatible motherboard’s design to boost clock speeds higher and for longer periods of time. It also allows you overclock the processor at the touch of a button.
AMD Ryzen Master Utility
Personalized Performance
The AMD Ryzen Master Utility provides you with multiple custom profiles to store CPU, GPU, and DDR4 memory configurations. Use it to configure performance parameters for the active cores and adjust memory times. You can also optimize general performance or fine tune your favorite applications.
System Monitoring
Monitor your system in real-time using the AMD Ryzen Master Utility, which features a histogram of per-core clock rates and temperature, including average and peak readings.
Specification :
| General | |
| CPU Model | AMD Ryzen 5 9600X |
| CPU Socket | AM5 |
| Manufacturing Process | 4 nm |
| Maximum CPU Configuration | 1S |
| Maximum Number of PCIe Lanes | 28 (Revision 5.0) |
| Unlocked | Yes |
| Supporting Chipsets | A620 , X670E , X670 , B650E , B650 , X870E , X870 |
| Performance | |
| Number of Cores | 6 |
| Number of Threads | 12 |
| Base Clock Speed | 3.9 GHz |
| Maximum Boost Speed | 5.4 GHz |
| L3 Cache | 32 MB |
| Memory Support | |
| Maximum Capacity | 192 GB |
| Memory Support | DDR5 Up to 5600 MHz |
| ECC Memory | Yes |
| Channel Architecture | Dual Channel |
| Power | |
| Thermal Design Power (TDP, Max) | 65 W |
| Included Thermal Solution | No |
| Maximum Temperature | 203°F / 95°C |
| Thermal Monitoring Technologies | Yes |
| Technology | |
| AES Support | Yes |
| Extension | AVX, AVX 2.0, AVX-512, FMA3, SSE 4.1/4.2 |
| Instruction Set | 64-Bit |
| Virtualization | Yes: AMD-V |
| Performance Technologies | Precision Boost 2 |
| Integrated Graphics | |
| Integrated Graphics | AMD Radeon |
| Output Support | DisplayPort, HDMI |
| Base Clock Speed | 2200 MHz |
| Packaging Info | |
| Package Weight | 0.195 lb |
| Box Dimensions (LxWxH) | 5.6 x 5 x 1.4″ |
