Cooler Master MasterBox 600 ATX Cabinet MB600-KGNN-S00
Overview :
The Masterbox 600 aims to bring high-level performance to every segment of the PC building community. We believe all users should be able to acheive the greatest heights of performance, so the Masterbox 600 is designed to deliver premium features and performance to te broadest user base possible.
The MasterBox 600 is prepared with space for a 420mm radiator and a 410mm GPU, back-connector motherboard support, which is the new standard for modern ATX cases.
Back-connected motherboard support
Supporting back-connected motherboard to frees up space in the front of the case, providing 33-35mm space behind the motherboard tray for easier cable management.
Versatile Cooling Options
Support for up to seven 120mm fans and either a top-mounted 360mm radiator or a front-mounted 420mm radiator allows for hyper-effective CPU cooling.
FineMesh Performance Front Panel
Large mesh intakes offer unrestricted airflow and stellar thermals for demanding systems.
Removable HDD cage
The HDD cage is completely removable for improved access during assembly and system upgrades.
Optimized airflow
3x 140mm Sickeflow fans, and a CF120 fan provide exceptional cooling power and eye-catching aesthetics.
Room For Upgrades
With support for a 410mm GPU, a 170mm CPU cooler, and multiple fans and radiators, the MasterBox 600 will ensure you stay ahead of the game.
Specification :
| Product Name | MasterBox 600 |
| Product Number | MB600-KGNN-S00 |
| Exterior Color | Black |
| Materials | |
| Exterior | Steel, Plastic |
| Side Panel | Tempered Glass |
| Dimensions | |
| Incl. Protrusions | 474mm x 230mm x 481mm |
| (L x W x H) | |
| Excl. Protrusions | 465mm x 230mm x 465mm |
| Volume (Liters Incl. Protrusions) | 49.73 L |
| Motherboard Support | ITX / Micro ATX / ATX (Supporting Back-connector Motherboard) / E-ATX (*up to 12″x10.9″/ 30.5cmx27.7cm motherboards, may impact cable management) |
| Expansion Slots | 7 |
| Drive Bays | |
| 5.25“ ODD | N/A |
| 3.5” HDD | 2 |
| 2.5” SSD | 2 (Max.6) |
| I/O Panel | |
| USB Ports | 2x USB 3.2 Gen1 Type A, 1x USB 3.2 Gen2x2 Type C |
| Audio In / Out | 1x 3.5mm Combo |
| Included Accessories | ARGB Fans Hub |
| Pre-installed Fan(s) | |
| Front | 3x 140mm SickleFlow140 ARGB PWM (650~1800 rpm) |
| Rear | 1x 120mm CF120 ARGB (650~1200 rpm) |
| Fan Support | |
| Front | 3x 120 / 3x 140mm |
| Top | 3x 120mm / 2x 140mm |
| Rear | 1x 120mm |
| Radiator Support | |
| Front | 120/140/240/280/360/420mm (Limit: 457*140*27mm) |
| Top | 120/140/240/280/360mm |
| Rear | 120mm |
| Clearances | |
| CPU Cooler | 170 mm |
| Power Supply | 170mm, 210mm (w/o HDD Cage) |
| Graphics Card | 360mm, 410mm (w/o front radiator) |
| Cable Routing | |
| Behind MB Tray | 33~35 mm |
| Dust Filters | Top/Bottom |
| Power Supply Support | ATX |
| Warranty | 2 years |
