Cooler Master MasterLiquid Lite 120 CPU Cooler AMD Socket AM4 MLW-D12M-A20PW-R1
Introducing the MasterLiquid Lite 120With its kink-resistant tubing and matt-black styling, the MasterLiquid Lite 120 is a Cooler Master original design and attractive entry into liquid cooling. Reliability, performance and quiet operation are ensured by its unique Dual Dissipation Pump and 120mm Air Balance fan design. Whether you’re building new or just upgrading, it’s easy to install on the latest Intel or AMD systems and 120mm radiator fits almost all PC chassis.
Specifications
| Product Name | MasterLiquid Lite 120 | |
| Model | MLW-D12M-A20PW-R1 | |
| CPU Socket | Intel® LGA 2011-v3 / 2011 / 1366 / 1151 / 1150 / 1156 / 1155 / 775 socket
AMD® AM4 / AM3 / AM3 / AM2 / AM2 / FM2 / FM2 / FM1 socket |
|
| Main System | Dimensions | 62 x 62 x 36.4 mm (2.4 x 2.4 x 1.4″) |
| Power Connector | 4-Pin | |
| Waterblock | Dimensions | 80.3 x 76 x 42.2mm (3.2 x 3.0 x 1.7″) |
| Pump | MTTF | 70,000 hours |
| Noise Level | < 8 dBA | |
| Connector | 3-Pin | |
| Rated Voltage | 12 VDC | |
| Load Current | 0.3 A | |
| Power Consumption | 3.96 W | |
| Radiator | Dimensions | 157 x 119.6 x 27mm (6.2 x 4.7 x 1.1″) |
| Material | Aluminum | |
| Fan | Dimension | 120 x 120 x 25 mm (4.7 x 4.7 x 1″) |
| Speed | 650 ~ 2000 RPM (PWM) ± 10% | |
| Air Flow | 66.7 CFM ± 10% | |
| Air Pressure | 2.34 mmH2O ± 10% | |
| MTTF | 160,000 hours | |
| Noise Level | 6-30 dBA | |
| Connector | 4-Pin (PWM) | |
| Rated Voltage | 12 VDC | |
