Fractal Design Define 7 Compact (ATX) Mid Tower Cabinet Black FD-C-DEF7C-01
Overview :
The new Define 7 Compact takes the strongest features of the contemporary 7 Series design and places them in a conveniently compact frame.
• Compact yet spacious interior fits ATX, mATX or Mini-ITX motherboards
• Fits GPUs up to 360 mm with a 240 mm radiator in the top
• Top panel effortlessly swaps from solid steel to filtered ventilation
Compact yet spacious
The versatile layout of the Define 7 Compact allows you to maximize the potential of the small footprint with full-size ATX hardware to meet your exact needs. For example, you can easily fit GPUs up to 360 mm with a 240 mm radiator in the top – or up to 360/280 mm front radiators with GPUs under 305 mm.
Remarkably quiet
Solid construction with industrial high-density sound damping helps maintain whisper-quiet operation
Brushed aluminum front and top-latching side panels offer a clean sophisticated look
Top panel effortlessly swaps from solid steel to filtered ventilation
Substantial cooling
Install up to 7x 120 mm or 4x 140 mm fans, and radiators up to 360 mm
1x 120 mm and 1x 140 mm Dynamic X2 fans included
Ventilated PSU shroud with two-part removable cover for optimal coverage and front radiator support
Specifications
| 3.5″/2.5″ drive mounts | 2 |
| Expansion slots | 7 |
| Total fan mounts | 7x 120 or 4x 140 mm and 2x 120 mm |
| Top fan | 2x 120 or 2x 140 mm |
| Bottom fan | 1x 120 mm (requires removal of HDD cage) |
| Fixed velcro straps | Yes |
| Captive thumbscrews | HDD brackets, SSD brackets, PSU bracket |
| Right side panel | Industrial sound-damped steel |
| Dedicated 2.5″ drive mounts | 2 trays included, 4 positions total |
| Front interface | 1x USB 3.1 Gen 2 Type-C, 2x USB 3.0, 2x USB 2.0, Audio I/O, Power button, Reset button |
| Front fan | 3x 120 or 2x 140 mm, (1x Dynamic X2 GP-14 included) |
| Rear fan | 1x 120 mm, (1x Dynamic X2 GP-12 included) |
| Dust filters | Top, 2x front, full length bottom |
| Cable routing grommets | Yes |
| Left side panel | Industrial sound-damped steel |
| Compatibility | |
| Motherboard compatibility | ATX / mATX / Mini-ITX |
| PSU max length | 200 mm total (165 mm w/ HDD cage and front fan) |
| CPU cooler max height | 169 mm |
| Top radiator | Up to 240 mm |
| Bottom radiator | 120 mm (requires removal of HDD cage) |
| Power supply type | ATX |
| GPU max length | 341 mm (360 mm without front fan) |
| Front radiator | Up to 360/280 mm (max 145 mm width) |
| Rear radiator | 120 mm |
| Cable routing space | 17-28 mm |
| Dimensions | |
| Case dimensions (LxWxH) | 427 x 210 x 474 mm |
| Case dimensions w/o feet/protrusions/screws | 415 x 210 x 451 mm |
| Package dimensions (LxWxH) | 536 x 310 x 521 mm |
| Net weight | 8.61 kg |
| Package weight | 10.87 kg |
| Volume | 39.3 liters |
| Warranty | 2 Years |
