Fractal Design Lumen S24 V2 Liquid Cooler FD-W-L1-S2411
Overview :
Lumen S24 V2
Customize your CPU water-cooling from subtle to stunning with Lumen’s six addressable LEDs that you can command via motherboard or controller. Compatible with most common Intel/AMD sockets, including LGA1700 and AM5 and RGB certified by industry standards, the Lumen offers high-end cooling performance and premium ARGB effects for new and seasoned builders alike.
• Duality design provides both a stealthy and illuminated look, controlled from your motherboard RGB UI
• Six ARGB LEDs are yours to command via your motherboard or controller
• The removable top can be turned at 90-degree intervals, making the logotype horizontal independent of the mounting orientation
• Compatible with LGA 1700 and AM5
Color-coordinated cooling
The right way up
The removable top can be turned at 90-degree intervals, making the logotype horizontal independent of the mounting orientation
Low-permeability rubber tubes with braided nylon sleeves
From subtle to stunning
Duality design provides both a stealthy and illuminated look, controlled from your motherboard RGB UI
Six ARGB LEDs are yours to command via your motherboard or controller
Powerful aspects
Aspect fans for low turbulence and chaining support
Forget the thermal paste
Thermal paste is pre-applied to ensure a proper and pain-free installation
Articulating elbow fittings make tubes easier to route and reduces tension on the cold plate housing
Common denominators
Compatible with LGA 1700 and AM5
Supports the most common sockets for both Intel and AMD
Color-coordinate your cooling
Compatible with ASUS AURA, Gigabyte Fusion, MSI Mystic Light, ASRock Polychrome and Razer Chroma
Technical Details
Brand : Fractal Design
Model : Lumen S24 V2
Technical Specs
Sockets supported (Intel) : LGA 1700*/1150/1151/1155/1156/1200 LGA 1366/2011/2011-3/2066
Sockets supported (AMD) : AM5 / AM4/FM2 /FM2/ FM1/AM3 /AM3/AM2 /AM2
* Compatible using updated LGA 1700 bracket, contact Fractal support to request one if using an older version
Cold plate material : Copper
Thermal paste : Pre-applied
Tube length : 400mm
Tube material : Low-permeability rubber with braided nylon sleeve
Fittings, block side : Articulating 90-degree Elbow
Fittings, radiator side : Barbed fitting
Block height : 43mm
Block measurements (with fittings) : 79 x 67 mm
Block diameter (main block body) : 67 mm
Fan specifications
Fan type : Aspect 12 PWM
Rotational speed : 500–2000 RPM
Fan bearing : Rifle bearings
Fan PWM control : Yes
Fan acoustical noise : <10–33.2 dBA
Fan maximum air flow : 13-56 CFM
Fan maximum static pressure : 0.230–2.34 mm H2O
Fan input voltage : 12V
Fan maximum input current : 0.37A
Fan MTTF : 90,000 hours
Pump specifications
Rotational speed : 4000 ± 10% RPM
Bearing type : Ceramic
PWM control : No
Acoustical noise (full speed) : 22 dBA
Maximum pressure : 1.8 mm H2O/ 17.6 kPa / 2.5 PSI
Input voltage : 12V DC
Input current (without fans) : 0.34 A
MTTF : 50 000 hours
Radiator specifications
Radiator dimensions : 272 x 120 x 27 mm
Radiator housing material : Aluminum
Radiator fin material : Aluminum
Radiator fan screw threads : 6-32
Other
Package contents : CPU Cooler Assembly, 2x Aspect 12 PWM fans, User manual, Intel mounting kit, AMD mounting kit, 5V ARGB cable
Package dimensions : 332 x 205 x 137 mm
Package weight : 1.77kg
