Fractal Design Meshify 2 Mid Tower Black Cabinet FD-C-MES2A-01
Overview :
The Meshify 2 is a high-performance case with a bold, stealth-inspired aesthetic. Its striking exterior features bolt-free, flush tempered glass, a fully removable top granting excellent interior access, and a fully redesigned front with USB-C, hinged mesh panel and removable nylon filter. The flexible dual-layout interior supports large storage arrays and multi-radiator setups that makes cooling a breeze.
Generous Space
Meshify 2’s roomy internal layout easily accommodates E-ATX motherboards up to 285 mm wide.
Extremely Flexible
Transformable interior design utilizing a movable wall for enhancing custom builds.
Smooth and Sturdy
The Meshify 2 is remarkably robust and comes with an angular asymmetrical style front mesh.
Flexible Dual-layout Design
There’s more than enough space for your custom water loop with large reservoirs and radiators up to 420 mm in the default Open Layout.
Detachable Front Filter
The new front nylon filter can easily be removed from the hinged mesh panel for increased airflow.
Superlative Storage
Convert to Storage Layout and install up to 14 HDDs alongside four dedicated SSDs mounts. (6x SSD/HDD trays, 2x SSD brackets and 1x Multibracket included)
Open and Interchangeable
Remove the entire top to build and route with zero hindrance. Swap in the ventilated panel to add three filtered fan positions.
Smooth Airflow
Three Dynamic X2 GP-14 fans come preinstalled with room to expand up to a total of nine fans.
Main Features
- Iconic angular mesh design provides filtered airflow with a bold, stealth-inspired aesthetic
- Spacious and extensively adaptable dual-layout interior easily accommodates large motherboards up to and including 285 mm E-ATX
- Support for radiators up to 360 mm in front, 420 mm up top, or 280 mm in the base in the default Open Layout
- Includes 6 HDD/SSD trays, 2 SSD brackets, and 1 universal Multibrackets for mounting up to 10 drives
- Expandable to 11 trays and 4 SSD brackets with 3 Multibrackets installed in the top and bottom for a max of up to 18 drives in Storage Layout
- New chassis design opens up to fully expose the case interior on three sides for totally unhindered installation and cable routing
- New front nylon filter that can be removed for increased airflow
- New front panel design with hinged removable mesh and tether-free bezel for easier access to front fan mounts
- Three front USB ports including one USB 3.1 Gen 2 Type-C with fast charging support and speeds up to 10Gbps
- Ultra-slim Nexus 2 fan hub connects up to three PWM fans and six 3-pin fans directly in line with cable channels along the edge of the case
- Outstanding cooling capacity with a total of nine 120/140 mm fan mounts and three preinstalled Dynamic X2 GP-14 fans
- Detachable PSU cable shield and integrated cable guides with velcro straps further simplify cable management behind the board
- Versatile Multibracket that converts any unused fan position to an HDD, SSD or pump mount
- Bridgeless expansion slots ensure obstruction-free connections and allow for a more centered vertical GPU installation via the new Flex B-20 PCIe riser (sold separately)
- Two vertical GPU slots for use with the Flex VRC-25 PCIe riser, available separately
- Easy-to-clean high airflow nylon filters on the front, top and base with full PSU coverage and convenient front access
- Ventilated PSU shroud with two-part removable cover for optimal cable concealment and front radiator support
- Tool-less, top-latching side panels allow quick access while preventing accidental drops
Specification :
| User Controls | |
| User Controls | Power |
| Reset | |
| Storage | |
| Internal Expansion Bays | 2 x 2.5″ |
| 6 x 2.5″/3.5″ | |
| Expansion | |
| Expansion Slots | 7 x Full Height |
| 2 x Vertical | |
| Interfaces/Ports | |
| USB Ports | 1 x USB 3.1 Type-C |
| 2 x USB 3.0 | |
| Headphone Ports | 1 x 3.5mm Jack |
| Microphone In Port | 1 x 3.5mm Jack |
| Electrical | |
| Cooling System | Front: Supports 3 x 140mm or 120mm fans (2 x 140mm fans included) |
| Top: Supports 3 x 140mm or 120mm fans | |
| Rear: Supports 1 x 140mm or 120mm fan (140mm fan included) | |
| Bottom: Supports 2 x 140mm or 120mm fans | |
| Power Supply | ATX Power Supply supported |
| Physical | |
| Form Factor | Mid Tower Case |
| Case Colour | Black with Solid Side Panel |
| Material | Steel |
| Motherboard Compatibility | E-ATX |
| ATX | |
| MicroATX | |
| Mini-ITX | |
| In The Box | Meshify 2 Case |
| User Manual | |
| Large Accessory Box (HDD Trays) | |
| Small Accessory Box | |
| Width | 240 mm |
| Depth | 542 mm |
| Height | 474 mm |
| Weight | 10.1 kg |
| Warranty | 2 Years |
| Key Features | |
| Firewire | No |
| Main Colour | Black |
| Case Type | Tower |
| USB 3.0 Support | Yes |
| Case Form Factor | Mid Tower |
| Power Supply Included | No |
| 80Plus Rated | No |
| PSU Form Factor | ATX |
| Display Model in Showroom | No |
| Illuminated | No |
| e-SATA | No |
| L.E.D Fan | No LED |
| Internal 3.5″ Bay | 6 |
| Internal 2.5″ Bay | 2 |
| ATX | Yes |
| Micro-ATX | Yes |
| ITX | Yes |
| E-ATX | Yes |
| Cooler Height | 185 mm |
| Built-in Card Reader | No |
| USB Type-C Support | Yes |
| Front HDMI | No |
| Side Panel Type | Solid |
| GPU Length | 315 mm |
| PSU Depth | 250 mm |
| Front Audio Type | Separate |
| Number of Fans | 3 fan(s) |
| LED Controller Included | No |
| LED Strip(s) Included | No |
| Maximum Motherboard Size Supported | E-ATX |
| Item Details | |
| Manufacturer | Fractal Design |
| Manufacturer Code | FD-C-MES2A-01 |
