Gigabyte GeForce RTX 4080 SUPER WINDFORCE 16G Graphic Card GV-N408SWF3-16GD
Overview :
THE EVOLVING POWER OF WINDFORCE
The WINDFORCE cooling system features three 110mm newly designed bionic shark fans, alternate spinning, 12 composite copper heat pipes, a large vapor chamber directly touches the GPU, 3D active fans and Screen cooling, which together provide high efficiency heat dissipation.
LARGE VAPOR CHAMBER & HEAT-PIPE
The large vapor chamber directly contacts the GPU, coupled with the composite heat pipes, which quickly transfers the heat of the GPU and VRAM to the heatsink.
LCD EDGE VIEW
The LCD monitor displays not only graphics card information, but also various favorite texts, pictures, and GIFs. You can also adjust lighting effects via GIGABYTE CONTROL CENTER.
RGB FUSION
The legendary three-ring lighting provides excellent visual enjoyment. You can choose any lighting effect or synchronize with other devices in GIGABYTE CONTROL CENTER
EXTREME OVERCLOCKING
The graphics card features excellent power phase design to allow the MOSFETs to operate at lower temperatures and provide a more stable voltage output. Load balancing of each MOSFET can effectively improve the overclocking performance and extend the life of the card.
ULTRA DURABLE
Ultra Durable certified highest-grade metal chokes, lower ESR solid capacitors, 2oz copper PCB, and lower RDS(on) MOSFETs, plus over-temperature design to deliver superior performance and longer system life.
FRIENDLY PCB DESIGN
Fully automated production process ensures top quality of the circuit boards and eliminates sharp protrusions of the solder connectors seen on the conventional PCB surface. This friendly design prevents your hands from getting cut or inadvertently damaging components when making your build.
Technical Detail
Brand : Gigabyte
Modal : GV-N408SAORUS M-16GD
Technical Spec
Graphics Processing : GeForce RTX™ 4080 SUPER
Core Clock : 2625 MHz (Reference card: 2550 MHz)
CUDA® Cores : 10240
Memory Clock ; 23 Gbps
Memory Size ; 16 GB
Memory Type : GDDR6X
Memory Bus : 256 bit
Card Bus : PCI-E 4.0
Digital max resolution : 7680×4320
Multi-view : 4
Card size : L=357 W=163 H=75 mm
PCB Form : ATX
DirectX : 12 Ultimate
OpenGL : 4.6
Recommended PSU : 850W
Power Connectors : 16 pin*1
Output
DisplayPort 1.4a *3
HDMI 2.1a *1
Accessories
1. Quick guide
2. Warranty registration
3. Anti-sag bracket
4. Anti-sag bracket installation guide
5. One 16 pin to triple 8-pin power adaptor
6. AORUS Metal sticker
