CPU |
AM4 Socket: Support for AMD Ryzen™ 2nd Generation/ Ryzen™ with Radeon™ Vega Graphics/ Athlon™ with Radeon™ Vega Graphics/ Ryzen™ 1st Generation Processors |
Chipset |
AMD B450 |
Memory |
2 x DDR4 DIMM sockets supporting up to 32 GB of system memory |
Dual channel memory architecture |
Support for DDR4 3200(O.C.)/2933/2667/2400/2133 MHz memory modules |
Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode) |
Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules |
Support for Extreme Memory Profile (XMP) memory modules |
|
Onboard Graphics |
1 x D-Sub port, supporting a maximum resolution of 1920×1200@60 Hz |
1 x DVI-D port, supporting a maximum resolution of 1920×1200@60 Hz |
* The DVI-D port does not support D-Sub connection by adapter. |
1 x HDMI port, supporting a maximum resolution of 4096×2160@60 Hz |
* Support for HDMI 2.0 version and HDCP 2.2. |
* Actual support may vary by CPU. |
|
Audio |
Realtek® ALC887 codec |
High Definition Audio |
2/4/5.1/7.1-channel |
* To configure 7.1-channel audio, you have to use an HD front panel audio module and enable the multi-channel audio feature through the audio driver. |
Support for S/PDIF Out |
|
LAN |
Realtek® GbE LAN chip (10/100/1000 Mbit) |
Expansion Slots |
1 x PCI Express x16 slot, running at x16 |
(The PCIEX16 slot conforms to PCI Express 3.0 standard.) |
|
2 x PCI Express x1 slot |
(The PCI Express x1 slot conforms to PCI Express 2.0 standard.) |
|
Storage Interface |
1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 SATA and PCIe x4/x2* SSD support) |
* Supports only M.2 SATA SSDs when using an AMD 7th Generation A-series or Athlon™ processor. |
|
4 x SATA 6Gb/s connectors |
Support for RAID 0, RAID 1, and RAID 10 |
|
USB |
Chipset: |
|
2 x USB 3.1 Gen 1 ports available through the internal USB header |
6 x USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through the internal USB headers) |
|
CPU: |
|
4 x USB 3.1 Gen 1 ports on the back panel |
|
Internal I/O Connectors |
1 x 24-pin ATX main power connector |
1 x 8-pin ATX 12V power connector |
1 x CPU fan header |
2 x system fan headers |
1 x M.2 Socket 3 connector |
4 x SATA 6Gb/s connectors |
1 x front panel header |
1 x front panel audio header |
1 x S/PDIF Out header |
1 x CPU cooler LED strip/RGB LED strip header |
1 x USB 3.1 Gen 1 header |
2 x USB 2.0/1.1 headers |
1 x Trusted Platform Module (TPM) header (2×10 pin, for the GC-TPM2.0 module only) |
1 x speaker header |
1 x serial port header |
1 x Clear CMOS jumper |
1 x chassis intrusion header |
|
Back Panel Connectors |
1 x PS/2 keyboard port |
1 x PS/2 mouse port |
1 x D-Sub port |
1 x DVI-D port |
1 x HDMI port |
4 x USB 3.1 Gen 1 ports |
2 x USB 2.0/1.1 ports |
1 x RJ-45 port |
3 x audio jacks |
|
I/O Controller |
iTE® I/O Controller Chip |
H/W Monitoring |
Voltage detection |
Temperature detection |
Fan speed detection |
Overheating warning |
Fan fail warning |
Fan speed control |
* Whether the fan speed control function is supported will depend on the cooler you install. |
|
BIOS |
1 x 128 Mbit flash |
Use of licensed AMI UEFI BIOS |
PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
|
Unique Features |
Support for APP Center |
* Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications. |
3D OSD |
@BIOS |
AutoGreen |
Cloud Station |
EasyTune |
Fast Boot |
Game Boost |
ON/OFF Charge |
RGB Fusion |
Smart Backup |
Smart Keyboard |
Smart TimeLock |
Smart HUD |
Smart Survey |
System Information Viewer |
USB Blocker |
|
Support for Q-Flash |
Support for Xpress Install |
|
Bundle Software |
Norton® Internet Security (OEM version) |
Realtek® 8118 Gaming LAN Bandwidth Control Utility |
|
Operating System |
Support for Windows 10 64-bit |
Support for Windows 7 64-bit |
* To support Windows 7 64-bit, you must install an AMD Pinnacle Ridge & Summit Ridge CPU. |
* Please download the “Windows USB Installation Tool” from GIGABYTE’s website and install it before installing Windows 7. |
|
Form Factor |
Micro ATX Form Factor; 24.4cm x 20.5cm |
Warranty |
3 Years |
