Gigabyte GeForce RTX 4070 Ti Super Aero OC 16GB GDDR6X Graphic Card GV-N407TSAERO OC-16GD
Overview :
Gigabyte GeForce RTX 4070 Ti Super Aero OC 16GB GDDR6X (GV-N407TSAERO OC-16GD)
NVIDIA Ada Lovelace Architecture Designed to Give You Superpowers
New Streaming Multiprocessors
Up to 2X performance and power efficiency
Fourth-Gen Tensor Cores
Up to 4X performance with DLSS 3
vs. brute-force rendering
Third-Gen RT Cores
Up to 2X ray tracing performance
WINDFORCE COOLING SYSTEM
The WINDFORCE cooling system features three 90mm unique blade fans, alternate spinning, 8 composite copper heat pipes, a copper plate directly touches the GPU, 3D active fans and Screen cooling, which together provide high efficiency heat dissipation.
ALTERNATE SPINNING
Reduce the turbulence of adjacent fans and increase airflow pressure.
3D ACTIVE FAN
The 3D Active Fan provides semi-passive cooling, and the fans will remain off when the GPU is in a low load or low power game
UNIQUE BLADE FAN
The airflow is spilt by the triangular fan edge, and guided smoothly through the 3D stripe curve on the fan surface.
GRAPHENE NANO LUBRICANT
Graphene nano lubricant can extend the life of fan by 2.1 times, close to the life of double ball bearing, and is quieter.
SCREEN COOLING
Extended heatsink design allows air flow to pass through, providing better heat dissipation.
LARGE COPPER PLATE & HEAT-PIPE
The large copper plate directly contacts the GPU, coupled with the composite heat pipes, which quickly transfers the heat of the GPU and VRAM to the heatsink.
RGB FUSION
With 16.7M customizable color options and numerous lighting effects, you can choose any lighting effect or synchronize with other devices in GIGABYTE CONTROL CENTER.
4-YEAR WARRANTY
We want you to experience the best service you have ever had. This is why, on top of our standard 3-year warranty, we would like to offer you an additional 1 year of protection to your graphics card free of charge. You can enjoy a 4-year warranty by registering on the website within 30 days of purchase.
Power Through The Game
GIGABYTE offers the best power supply solutions for your graphics cards. You can choose either the AORUS series or the UD series to power your graphics card.
GIGABYTE CONTROL CENTER
GIGABYTE CONTROL CENTER is a unified software for all GIGABYTE supported products. It provides an intuitive interface that allows users to adjust clock speed, voltage, fan mode and power target in real-time.
Key Feature
Powered by NVIDIA DLSS 3, ultra-efficient Ada Lovelace arch, and full ray tracing
4th Generation Tensor Cores: Up to 4X performance with DLSS 3 vs. brute-force rendering
3rd Generation RT Cores: Up to 2X ray tracing performance
Powered by GeForce RTX™ 4070 Ti SUPER
Integrated with 16GB GDDR6X 256bit memory interface
WINDFORCE Cooling System
RGB Fusion
Dual BIOS
Protection metal back plate
Anti-sag bracket
4 Years Warranty
CORE CLOCK 2655 MHz (Reference card: 2610 MHz)
Technical Detail
Brand : Gigabyte
Model : GV-N407TSAERO OC-16GD
Technical Spec
Graphics Processing : GeForce RTX 4070 Ti SUPER
Core Clock : 2655 MHz (Reference card: 2610 MHz)
CUDA® Cores : 8448
Memory Clock : 21 Gbps
Memory Size : 16 GB
Memory Type : GDDR6X
Memory Bus : 256 bit
Card Bus : PCI-E 4.0
Digital max resolution : 7680×4320
Multi-view : 4
Card size : L=300 W=130 H=57.6 mm
PCB Form : ATX
DirectX : 12 Ultimate
OpenGL : 4.6
Recommended PSU : 750W
Power Connectors : 16 pin *1
Output
DisplayPort 1.4a *3
HDMI 2.1a *1
