GIGABYTE GP-B700H 700W SLI CrossFire 80 PLUS BRONZE Modular PSU
Features
- Modular Design
- High quality Japanese electrolytic capacitors
- 120mm smart control fan
- 80 Plus Bronze certified
- Single 12V rail
- Supports NVIDIA SLI / AMD CROSSFIRE
Modular Design
The black flat cables are modular. Installing only the cables you need to increase the airflow and to improve the chassis thermal performance.
High Quality Japanese Electrolytic Capacitors
Main electrolytic capacitors are high quality Japanese electrolytic capacitors, to produce the efficient performance and to ensure the longer reliability.
120mm Smart Control Fan
120mm cooling fan with smart control system optimizes the noise reduction and the performance. The fan speed is adjusted according to the automatic power detection. The ball bearing fan provides longer and more stable life time.
80 Plus Bronze Certified
80 Plus certified ensures the better power efficiency. Less power waste reduces the heat and fan noise.
Single 12V Rail
Single 12V rail provides the best power output, stability and compatibility for the hardware. And it is the best design for overclocking.
Specification :
| Model | B700H |
| Type | Intel Form Factor ATX 12V v2.31 |
| PFC | Active PFC (>0.9 typical) |
| Input Voltage | 100-240 Vac (full range) |
| Input Current | 10A |
| Input Frequency | 47-63 Hz |
| Output Capacity | 700W |
| Dimension | D140 x W150 x H86mm |
| Fan Type | 120mm Double ball bearing fan |
| Efficiency | 85% at typical load |
| MTBF | >100,000 hours |
| Protection | OVP/OPP/SCP/UVP |
| Regulatory | CE/BSMI/EAC/TUV/FCC/UL/RCM/KCC/CCC |
| Cable Type | Black Flat Cables |
| Connectors | MB 20 4 Pin x1 |
| CPU 4 4 Pin x1 | |
| PCI-e 6 2 Pin x4 | |
| SATA x7 | |
| 4Pin Peripheral x3 | |
| 4Pin Floopy x1 |
