Gigabyte X570S AORUS Elite AX (Wi-Fi) Motherboard
Overview :
- Dual Channel ECC/ Non-ECC Unbuffered DDR4, 4 DIMMs
- Twin 12 2 Phases Digital VRM Solution with 60A DrMOS
- Fully Covered Thermal Design with High Coverage MOSFET Heatsinks
- AMD WiFi 6E 802.11ax & BT 5.2
- Triple Ultra-Fast NVMe PCIe 4.0/3.0 x4 M.2 with Thermal Guards
- Fast 2.5GbE LAN with Bandwidth Management
- SuperSpeed USB 3.2 Gen 2×2 TYPE-C® delivers up to 20Gb/s transfer speeds
- AMP-UP Audio with ALC1220-VB and WIMA Audio Capacitors
- Smart Fan 6 Features Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP
- RGB FUSION 2.0 with Multi-Zone Addressable LED Light Show Design, Support Addressable LED & RGB LED Strips
- Q-Flash Plus Update BIOS without Installing the CPU, Memory and Graphics Card
Specification :
CPU | |
1. AMD Socket AM4, support for: AMD Ryzen™ 5000 Series/ Ryzen™ 5000 G-Series/ AMD Ryzen™ 4000 G-Series/ AMD Ryzen™ 3000 Series/ AMD Ryzen™ 3000 G-Series/ AMD Ryzen™ 2000 Series/ AMD Ryzen™ 2000 G-Series Processors | |
(Please refer “CPU Support List” for more information.) | |
Chipset | AMD X570 |
Memory | |
1. 4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory | |
2. Dual channel memory architecture | |
3. Support for DDR4 5400(O.C.) / 5300(O.C.) / 5200(O.C.) / 5100(O.C.) / 4800(O.C.) / 4600(O.C.) / 4400(O.C.) / 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3733(O.C.) / 3600(O.C.) / 3466(O.C) / 3400(O.C.) / 3200(O.C.) / 2933 / 2667 / 2400 / 2133 MHz memory modules | |
4. Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules* | |
* ECC memory (ECC mode) support varies by CPU | |
5. Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules | |
6. Support for Extreme Memory Profile (XMP) memory modules | |
(Please refer “Memory Support List” for more information.) | |
Onboard Graphics | Integrated Graphics Processor: |
1. 1 x HDMI port, supporting a maximum resolution of 4096×2160@60 Hz | |
* Support for HDMI 2.1 version, HDCP 2.3, and HDR. | |
Maximum shared memory of 16 GB | |
Audio | |
1. Realtek® ALC1220-VB codec | |
* The back panel line out jack supports DSD audio. | |
2. High Definition Audio | |
3. 2/4/5.1/7.1-channel | |
4. Support for S/PDIF Out | |
LAN | Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps) |
Wireless Communication module | AMD Wi-Fi 6E RZ608 (MT7921K) |
1. WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands | |
2. BLUETOOTH 5.2 | |
3. Support for 11ax 80MHz wireless standard and up to 1.2 Gbps data rate | |
(Actual data rate may vary depending on environment and equipment.) | |
Expansion Slots | 1 x PCI Express x16 slot (PCIEX16), integrated in the CPU: |
1. AMD Ryzen™ 5000 Series/3000 Series Processors support PCIe 4.0 x16 mode | |
2. AMD Ryzen™ 5000 G-Series/4000 G-Series/2000 Series Processors support PCIe 3.0 x16 mode | |
3. AMD Ryzen™ 3000 G-Series/2000 G-Series Processors support PCIe 3.0 x8 mode | |
* For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot. | |
1 x PCI Express x16 slot (PCIEX4), integrated in the Chipset: | |
1. Supporting PCIe 4.0(Note)/3.0 x4 mode | |
1 x PCI Express x16 slot (PCIEX2), integrated in the Chipset: | |
1. Supporting PCIe 4.0(Note)/3.0 x2 mode | |
* The PCIEX4 slot shares bandwidth with the PCIEX2 slot. When the PCIEX2 slot is populated, the PCIEX4 slot operates at up to x2 mode. | |
(Note) For AMD Ryzen™ 5000 Series Processors/AMD Ryzen™ 3000 Series Processors only. | |
Multi-Graphics Technology | |
1. Support for AMD Quad-GPU CrossFire™ and 2-Way AMD CrossFire™ technologies | |
(Note) For AMD Ryzen™ 5000 Series/5000 G-Series/4000 G-Series/3000 Series/2000 Series Processors only | |
Storage Interface | 1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M key, type 2260/2280/22110 SSDs: |
1. AMD Ryzen™ 5000 Series/3000 Series Processors support SATA and PCIe 4.0 x4/x2 SSDs | |
2. AMD Ryzen™ 5000 G-Series/4000 G-Series/3000 G-Series/2000 Series/2000 G-Series Processors support SATA and PCIe 3.0 x4/x2 SSDs | |
2 x M.2 connectors (M2B_SB/M2C_SB), integrated in the Chipset, supporting Socket 3, M key, type 2260/2280/22110 SSDs: | |
1. Supporting SATA and PCIe 4.0(Note)/3.0 x4/x2 SSDs | |
6 x SATA 6Gb/s connectors, integrated in the Chipset: | |
1. Support for RAID 0, RAID 1, and RAID 10 | |
* Refer to “1-7 Internal Connectors,” for the installation notices for the M.2 and SATA connectors. | |
USB | CPU: |
1. 4 x USB 3.2 Gen 1 ports on the back panel | |
Chipset ASMedia® USB 3.2 Gen 2×2 Controller: | |
1. 1 x USB Type-C® port on the back panel, with USB 3.2 Gen 2×2 support | |
Chipset: | |
1. 1 x USB Type-C® port with USB 3.2 Gen 2 support, available through the internal USB header | |
2. 3 x USB 3.2 Gen 2 Type-A ports (red) on the back panel | |
3. 4 x USB 3.2 Gen 1 ports available through the internal USB headers | |
Chipset 2 USB 2.0 Hubs: | |
1. 8 x USB 2.0/1.1 ports (4 ports on the back panel, 4 ports available through the internal USB headers) | |
Internal I/O Connectors | |
1. 1 x 24-pin ATX main power connector | |
2. 1 x 8-pin ATX 12V power connector | |
3. 1 x CPU fan header | |
4. 1 x water cooling CPU fan header | |
5. 3 x system fan headers | |
6. 1 x system fan/water cooling pump header | |
7. 2 x addressable LED strip headers | |
8. 2 x RGB LED strip headers | |
9. 1 x CPU cooler LED strip/RGB LED strip header | |
10. 3 x M.2 Socket 3 connectors | |
11. 6 x SATA 6Gb/s connectors | |
12. 1 x front panel header | |
13. 1 x front panel audio header | |
14. 1 x USB Type-C® header, with USB 3.2 Gen 2 support | |
15. 2 x USB 3.2 Gen 1 headers | |
16. 2 x USB 2.0/1.1 headers | |
17. 1 x Trusted Platform Module (TPM) header (2×6 pin, for the GC-TPM2.0_S module only) | |
18. 1 x Thunderbolt™ add-in card connector | |
19. 1 x Clear CMOS jumper | |
*All fan headers are subject to support AIO_Pump, Pump and high performance fan with the capability of delivering up to 2A/12V @ 24W. | |
Back Panel Connectors | |
1. 4 x USB 2.0/1.1 ports | |
2. 2 x SMA antenna connectors (2T2R) | |
3. 1 x HDMI port | |
4. 4 x USB 3.2 Gen 1 ports | |
5. 1 x Q-Flash Plus button | |
6. 1 x USB Type-C® port, with USB 3.2 Gen 2×2 support | |
7. 3 x USB 3.2 Gen 2 Type-A ports (red) | |
8. 1 x RJ-45 port | |
9. 1 x optical S/PDIF Out connector | |
10. 5 x audio jacks | |
I/O Controller | iTE® I/O Controller Chip |
H/W Monitoring | |
1. Voltage detection | |
2. Temperature detection | |
3. Fan speed detection | |
4. Water cooling flow rate detection | |
5. Fan fail warning | |
6. Fan speed control | |
* Whether the fan (pump) speed control function is supported will depend on the fan (pump) you install. | |
BIOS | |
1. 1 x 256 Mbit flash | |
2. Use of licensed AMI UEFI BIOS | |
3. PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 | |
Unique Features | |
1. Support for APP Center | |
* Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications. | |
@BIOS | |
EasyTune | |
Fast Boot | |
Game Boost | |
ON/OFF Charge | |
RGB Fusion | |
Smart Backup | |
System Information Viewer | |
2. Support for Q-Flash Plus | |
3. Support for Q-Flash | |
4. Support for Xpress Install | |
Bundled Software | |
1. Norton® Internet Security (OEM version) | |
2. Realtek® 8125 Gaming LAN Bandwidth Control Utility | |
Operating System | Support for Windows 10 64-bit |
Form Factor | |
1. ATX Form Factor; 30.5cm x 24.4cm | |
Warranty | 3 Years |
