Intel Core i5-13600KF 3.5 GHz 14-Core LGA 1700 Processor BX8071513600KF
Overview :
Power up your productivity, gaming, and content creation with the Intel Core i5-13600KF 3.5 GHz 14-Core LGA 1700 Processor. This 13th generation desktop processor builds upon the Hybrid Core architecture and Intel 7 process by fitting 14 cores— four more than the previous generation— onto a single processor while still fitting the LGA 1700 socket. Designed to provide strong performance for everyday tasks, the Core i5-13600KF features eight low-voltage Efficient-cores that handle background tasks for multitasking while the six 3.5 GHz Performance-cores power applications and games. The built-in Intel Thread Director ensures that the two work seamlessly together by dynamically and intelligently assigning workloads to the right core at the right time.
With 24MB of cache and a 5.1 GHz Turbo Boost Max 2.0 frequency, this processor is made to handle a variety of applications. You can also overclock this processor for even greater performance. The Core i5-13600KF also supports PCI Express 5.0 and dual-channel DDR5 memory at 5600 MHz.
The Core i5-13600KF does not include integrated graphics, meaning that users will need to purchase a separate dedicated graphics card. Please note that a thermal solution NOT is included. This processor is backed by a 3-year warranty.
Hybrid Core Design
Performance-cores provide the speed to handle high-end games and demanding applications while low-priority and background tasks are handled by the processor’s Efficient-cores for multitasking.
Intel Thread Director
The Intel Thread Director is built into the CPU’s cores, working with the operating system to ensure each of the 20 threads are assigned to the right core at the right time.
PCIe 4.0 & 5.0
This processor supports up to four PCIe 4.0 and sixteen PCIe 5.0 lanes, delivering 20 lanes in total for exceptional data throughput with compatible devices.
Gaussian & Neural Accelerator 3.0
Gaussian and Neural Accelerator 3.0 (GNA) technology helps with noise suppression while enhancing background blurring during video chats.
Intel Deep Learning Boost
Accelerates AI inference to improve performance for deep learning workloads.
Specification :
| General | |
| CPU Model | Intel Core i5-13600KF (13th Gen) |
| CPU Socket | LGA 1700 |
| Manufacturing Process | 10 nm |
| Maximum CPU Configuration | 1S |
| Maximum Number of PCIe Lanes | 16 (Revision 5.0) |
| 4 (Revision 4.0) | |
| Unlocked | Yes |
| Performance | |
| Number of Cores | 14 (6 x P-Cores 8 x E-Cores) |
| Number of Threads | 20 |
| Base Clock Speed | P-Core: 3.5 GHz |
| E-Core: 2.6 GHz | |
| Maximum Boost Speed | P-Core Turbo: 5.1 GHz |
| E-Core Turbo: 3.9 GHz | |
| L3 Cache | 24 MB |
| Memory Support | |
| Maximum Capacity | 128 GB |
| Memory Support | DDR5 5600 MHz |
| DDR4 3200 MHz | |
| ECC Memory | No |
| Channel Architecture | Dual Channel |
| Optane Memory Support | Yes |
| Power | |
| Thermal Design Power (TDP) | 125 W |
| Included Thermal Solution | None |
| Maximum Temperature | 212°F / 100°C |
| Thermal Monitoring Technologies | Yes |
| Technology | |
| AES Support | Yes |
| Extension | AVX 2.0, AVX-512, SSE 4.1/4.2 |
| Instruction Set | 64-Bit |
| Virtualization | Yes: Intel VT-d, Intel VT-x, Intel VT-x with Extended Page Tables (EPT) |
| vPro Support | No |
| Performance Technologies | Deep Learning Boost, Gaussian and Neural Accelerator 3.0, Hyper-Threading, Intel Thread Director, SpeedShift, SpeedStep, Turbo Boost 2.0 |
| Security Technologies | Control-Flow Enforcement (CET), Device Protection with Boot Guard, Execute Disable Bit, MBE (Mode-Based Execute) Control, OS Guard, Secure Key, Software Guard Extensions, Threat Detection Technology (TDT), Trusted Execution Technology |
| Integrated Graphics | None |
