MSI EdgeXpert Compact Desktop AI Supercomputer EdgeXpert
Overview :
- NVIDIA® Grace Blackwell (GB10) Architecture:
– NVIDIA Blackwell GPU & Arm 20-core CPU
– NVIDIA® NVLink®-C2C CPU-GPU memory interconnect - 128 GB LPDDR5x coherent, unified system memory
- 1000 AI TOPS (FP4) AI performance
- Full stack solution, hardware & software, designed for AI developers
The MSI EdgeXpert AI Supercomputer redefines desktop AI computing, delivering petaflop-scale performance through the cutting-edge NVIDIA® GB10 Grace Blackwell Superchip—the same powerhouse at the core of NVIDIA DGXTM Spark. Purpose- built for developers, AI researchers, and data scientists, the EdgeXpert empowers local AI development with unmatched performance, scalability, and advanced features—all in a compact, desktop-ready form.
NVIDIA® Grace Blackwell Architecture
NVIDIA Blackwell GPU & Arm 20 core CPU
Optimizes data preprocessing and orchestration to accelerate model tuning and enable real-time inference with greater efficiency.
NVLink®-C2C Technology
Offers a seamless CPU+GPU memory model with up to five times the bandwidth of PCIe 5.0, ensuring ultra-fast data access and transfer.
Unmatched AI ComputingPower
1000 AI TOPS (FP4) Tensor Performance
Delivers blazing-fast performance for effortlessly running complex AI workloads at scale.
128 GB LPDDR5x, unified system memory
Provides the large memory needed for smooth model development, rapid experimentation, and high-efficiency inference.
Running and scaling LLMs locally, from 200B to 405B parameters
Supports AI models with up to 200 billion parameters
Run LLMs locally for data security, low latency, cost control, and full AI workflow—prototyping, fine-tuning, and inference.
Stack via NVIDIA ConnectX: Large AI models &Performance
High-performance NVIDIA ConnectX networking enables two MSI systems together to work with AI models up to 405 billion parameters.
Specification :
| Architecture | NVIDIA® Grace Blackwell GB10 |
| GPU | NVIDIA® Blackwell Architecture |
| CPU | 20 core Arm, 10 Cortex-X925 + 10 Cortex-A725 Arm |
| Tensor Performance1 | 1000 AI TOPS (FP4, Sparse) |
| System Memory | 128 GB LPDDR5x, unified system memory |
| Memory Interface | 256-bit |
| Memory Bandwidth | 273 GB/s |
| Storage | 1 or 4 TB NVME.M2 with self-encryption |
| USB | 4x USB 3.2 Type C |
| Ethernet | 1x RJ-45 connector 10 GbE |
| NIC | ConnectX-7 Smart NIC |
| Wi-Fi | WiFi 7 |
| Bluetooth | BT 5.4 |
| Audio-output | HDMI multichannel audio output |
| Display Connectors | 1x HDMI 2.1a |
| NVENC | NVDEC | 1x | 1x |
| OS | NVIDIA DGX™ OS |
| System Dimensions | 151 mm L x 151 mm W x 52 mm H (1.19L) |
| System Weight | 1.2 kg |
