NZXT C1000 1000W 80 PLUS Gold Fully Modular ATX Power Supply PA-0G1BB-IN
Overview :
This PSU delivers 1000 watts of clean, stable power and is ideal for gaming and workstation PCs that have multiple GPUs and high-performance CPUs. The C1000 supports the latest GPUs, including up to an NVIDIA RTX 3090 and AMD GPUs up to the 6900 XT.
Specification :
| OUTPUT CONNECTORS | |
| 24-pin ATX power | 1 |
| 4 4-pin CPU power | 2 |
| 6 2-pin PCIe power | 6 |
| SATA power | 6 |
| Peripherals | 6 |
| CABLE SPECS | |
| 24-pin ATX power | 600 mm, Nylon sleeving |
| 4 4-pin CPU power | 700 mm, Nylon sleeving |
| 6 2-pin PCIe power | 650 150 mm, Nylon sleeving |
| SATA power | 500 150 mm |
| Peripherals | 500 150 mm |
| AC INPUT RATING | |
| 100 – 240Vac | 13A-6.5A 50Hz-60Hz |
| DC OUTPUT RATING | |
| 3.3V and 5V | 22A (120W) |
| 12V | 83.5A (1002W) |
| -12V | 0.3A (3.6W) |
| 5Vsb | 3A (15W) |
| Total | 1000W |
| OPERATION | |
| PF Correction | Active @0.96 |
| MTBF | 100,000 hours |
| Temperature | 0 – 50 °C (derating from 100% to 80% from 40 °C to 50 °C) |
| ENERGY EFFICIENCY | |
| Rating | 80 Plus Gold |
| 20% loading | 87% @115Vac |
| 50% loading | 90.5% @115Vac |
| 100% loading | 87.5% @115Vac |
| FAN SPECS | |
| Dimensions | 135 x 135 x 25 mm |
| Speed | 0-2300 ± 10% RPM |
| Airflow | 93.02 CFM (Tpy.) |
| Noise | 44.5 dBA max |
| Bearing | Fluid Dynamic Bearing (FDB) |
| GENERAL | |
| Dimensions | 150 x 150 x 86mm |
| Material(s) | Steel, PCB and Plastic |
| Compliance Standard | ATX12V v2.52 / EPS12V v2.92 |
| Regulation & Certification | cTUV-SUDus / CUL (UL60950/62368-1) / TUV / (EN60950/62368-1) / CB/ (IEC 950/62368-1) / CCC / CEC /BSMI / RCM / EAC / CE / LVD / UKCA |
| Warranty | 10 years |
| Model Number | PA-0G1BB-IN |
