Super Flower Leadex Titanium 1600 Watt Power Supply SF-1600F14HT
Overview :
LEADEX Titanium series PSU are 80+ Titanium certified with 100% fully modular cable design, our R&D team’s latest innovation, a brilliant idea to maximize PSU cables & connectors management to have the best cable routing solution, also increase case chassis air flow to have best cooling for your system.
LEADEX series PSU provides high efficiency & stable power output and come with a 14cm two-way thermal control intelligent cooling fan to ensure your professional PC system will work under heavy load, also capable of powering your PC system equipped with NVIDIA® SLI™ or ATI CrossFireX™ setup.
Specification :
| Model No. | SF-1600F14HT |
| Wattage | 1600W |
| 80+ Efficiency | 10%: 90%; 20%: 92% ; 50% : 94% ; 100% : 90% (115V Internal Titanium) |
| Intel Power Design Guide | V2.92 |
| AC Input / Frequency | 100-240V | 60 / 50Hz |
| Fan Size | 140mm Two-Ball Bearing Fan |
| Dimension | 220mm(L) x 150mm(W) x 86mm(H) |
| Protection | OVP/ OCP/ OPP/ SCP/ UVP/ OTP/ NLO/ SIP |
| Safety | cTÜVus / TÜV / CB / CE / FCC / RCM / RoHS / KCC / CQC |
| Temprature | Passed 50℃ Hot Testing |
| Cable Spec | |
| Detachable Cables | |
| 20+4Pin | One cable (600mm) |
| 8 (4+4) Pin CPU | Two cables (750mm) |
| PCI-E 6+2Pin | Four cables (750mm) |
| SLI (2 x PCI 6+2Pin) | Five cables (750+150mm) |
| 4SATA | Three cables (550+100+100+1000mm) |
| 2SATA+2Molex | One cable (550+100+100+100mm) |
| 3Molex | One cable (550+100+100mm) |
| Molex to FDD Adapter | Two cables (100mm) |
