Supermicro X12SCV-LVDS Motherboard Mini-ITX Single Socket LGA-1200 (Socket H5) for Intel Xeon W-1200, 10th Gen Intel Core i9/i7/i5/i3 Processors MBD-X12SCV-LVDS-O
Overview :
Motherboard Mini-ITX Single Socket LGA-1200 (Socket H5) for Intel Xeon W-1200 Processors, 10th Gen Intel Core i9/i7/i5/i3 Processors Up to 64GB DDR4-2933MHz ECC/non-ECC SODIMM in 2 DIMM slots 2x SATA3 port (RAID 0,1), 1 SuperDOM (Disk on Module) ports 2x Gigabit LAN Ports 1 PCI-E 3.0 x16 slots (16/NA or 8/8), M.2 Form Factor: 2242/2280, 3042 (M-Key, E-Key) (MBD-X12SCV-LVDS-O)
Specification :
| System Memory | |
| Memory Capacity | 2 DIMM slots |
| Up to 64GB ECC/non-ECC SODIMM, DDR4-2933MHz | |
| Memory Type | 2933/2666/2400/2133 MT/s ECC/non-ECC DDR4 SODIMM |
| DIMM Sizes | 4GB, 8GB, 16GB, 32GB |
| Memory Voltage | 1.2V |
| Error Detection | Corrects single-bit errors |
| Detects double-bit errors (using ECC memory) | |
| On-Board Devices | |
| Chipset | Intel® W480E |
| Audio | ALC 888S HD Audio |
| Graphics | 3 Independent Displays thru HDMI 2.0a/HDMI1.4/DP/LVDS |
| 1 Intel® HD Graphics port(s) | |
| Network Controllers | Single LAN with Intel® Ethernet Controller I210-AT |
| Single LAN with Intel® PHY I219LM LAN controller | |
| SATA | Intel® W480E controller for 2 SATA3 (6 Gbps) ports; RAID 0,1 |
| Input / Output | |
| LAN | 2 RJ45 Gigabit Ethernet LAN ports |
| Video Output | 1 DP (DisplayPort) port(s), 2 HDMI port(s), 1 LVDS port(s) |
| DOM | 1 Super DOM (Disk on Module) ports |
| SATA | 2 SATA3 (6Gbps) port(s) |
| USB | 4 USB 2.0 port(s) (4 via header) |
| 4 USB 3.2 Gen2 port(s) (4 rear type A) | |
| Serial Port | 2 COM ports via 1 header |
| TPM | 1 TPM Header & Chip both |
| System BIOS | |
| BIOS Type | AMI UEFI |
| BIOS Features | RTC (Real Time Clock) Wakeup |
| UEFI 2.7 | |
| PCI FW 3.0 | |
| ACPI 6.1 | |
| SMBIOS 3.1 | |
| Management | |
| Software | SuperDoctor® 5, NMI, AMT, vPro, Watchdog |
| System Management Software | SuperDoctor 5 |
| Power Configurations | ATX Power connector, ACPI / ACPM Power Management, +12V DC Power Input |
| PC Health Monitoring | |
| Voltage | VBAT, System temperature, System level control, PCH temperature, Monitors CPU voltages, HT, CPU temperature, Chipset Voltage, 3 -fan status, +3.3V, +1.8V |
| LED | Power LED |
| Temperature | Thermal Control for 3 Fan Connectors |
| Other Features | WOL, System level control, RoHS, M.2 NGFF connector, Chassis intrusion header, ATX Power connector, ACPI power management, 8-pin 12v DC power connector, 12V DC or ATX Power Source |
| FAN | Fan speed control |
| PWM fan speed control | |
| System level control | |
| 3x 4-pin fan headers (up to 3 fans) | |
| 3 fans with tachometer monitoring | |
| Product SKUs | |
| Product SKUs | MBD-X12SCV-LVDS |
| Physical Stats | |
| Form Factor | Mini-ITX |
| Dimension | 6.7″ x 6.7″ (17.02cm x 17.02cm) |
| Processor | |
| CPU | Intel® Xeon® W-1200 Processors , 11th/10th Generation Intel® Core™ i9/Core™ i7/Core™ i5/Core™ i3 Processor |
| Single Socket LGA-1200 (Socket H5) supported, CPU TDP supports Up to 65W TDP | |
| Core | Up to 10 cores |
| Note | ** Motherboard supports this maximum TDP. Please verify your system can thermally support. **The X12SCV-LVDS does not support the Intel 10th/11th generation processor 2M cache SKUs. These processors will not boot with the latest BIOS version. |
| Expansion Slots | |
| PCIe | 1 PCIe 3.0 x16 slots (16/NA or 8/8) |
| M.2 | M.2 Interface: 1 CNVi/PCIe 3.0 x1; 1 SATA/PCIe 3.0 x4 |
| Form Factor: 2230, 2242/2280 | |
| Key: E-Key, M-Key | |
| Operating Environment | |
| Operating Temperature Range | 0°C – 60°C (32°F – 140°F) |
| Non-Operating Temperature Range | -40°C – 85°C (-40°F – 185°F) |
| Operating Relative Humidity Range | 10% – 85% (non-condensing) |
| Non Operating Relative Humidity Range | 10% – 95% (non-condensing |
