Synology DiskStation DS924 Tower 4-Bay NAS Enclosure
Overview :
Featured dual 1GbE LAN ports to support network failover, and with Link Aggregation enabled, DS220 provides over 225 MB/s sequential read and 192 MB/s sequential write throughput. Data can be further protected with RAID 1 disk mirroring to prevent sudden drive failure.
Intel dual-core processor with AES-NI hardware encryption engine; 2 GB DDR4 memory (expandable up to 6 GB)
Access, share, and sync your data easily across different operating systems and devices.
Average 15% performance boost to photo indexing and other computing-intensive operations, as well as database response time.
Check Synology knowledge center or YouTube channel for help on product setup and additional information
Check the product specification page for the software or application you want to use
SATA device only
Specification :
| CPU | CPU Model | Realtek RTD1619B |
|---|---|---|
| CPU Quantity | 1 | |
| CPU Architecture | 64-bit | |
| CPU Frequency | 4-core 1.7 GHz | |
| Hardware Encryption Engine | ||
| Memory | System Memory | 2 GB DDR4 non-ECC |
| Notes | Synology reserves the right to replace memory modules with the same or higher frequency based on supplier’s product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance. | |
| Storage | Drive Bays | 4 |
| Compatible Drive Type* (See all supported drives) |
|
|
| Hot Swappable Drive* | ||
| Notes | “Compatible drive type” indicates drives that have been tested to be compatible with Synology products. This term does not indicate the maximum connection speed of each drive bay. | |
| External Ports | RJ-45 1GbE LAN Port* | 2 (with Link Aggregation / Failover support) |
| USB 3.2 Gen 1 Port* | 2 | |
| Notes |
|
|
| File System | Internal Drives |
|
| External Drives |
|
|
| Appearance | Size (Height x Width x Depth) | 184 mm x 168 mm x 230 mm |
| Weight | 2.21 kg | |
| Others | System Fan | 80 mm x 80 mm x 2 pcs |
| Fan Speed Mode |
|
|
| Brightness Adjustable Front LED Indicators | ||
| Power Recovery | ||
| Noise Level* | 20.6 dB(A) | |
| Scheduled Power On / Off | ||
| Wake on LAN / WAN | ||
| Power Supply Unit / Adapter | 90 W | |
| AC Input Power Voltage | 100V to 240V AC | |
| Power Frequency | 50/60 Hz, Single Phase | |
| Power Consumption | 32.41 W (Access) 4.97 W (HDD Hibernation) |
|
| British Thermal Unit | 110.52 BTU/hr (Access) 16.95 BTU/hr (HDD Hibernation) |
|
| Notes |
|
|
| Temperature | Operating Temperature | 0°C to 40°C (32°F to 104°F) |
| Storage Temperature | -20°C to 60°C (-5°F to 140°F) | |
| Relative Humidity | 5% to 95% RH | |
| Certification |
|
|
| Warranty | 2-year hardware warranty, extendable to 4 years with Extended Warranty Plus | |
| Notes |
|
|
| Environment | RoHS Compliant | |
| Packaging Content |
|
|
| Optional Accessories |
|
|
