Synology RS1221+ RackStation 8-Bay Diskless Rackmount Network Attached Storage NAS Device
Overview :
This NAS device supports up to 8 x 3.5″/2.5″ SATA HDD/SSD drives, providing flexible storage options. It can be expanded to 12 bays with the Synology RX418 expansion unit, allowing for significant storage scalability.
Processor: Powered by an AMD Ryzen V1500B quad-core 2.2GHz processor, it delivers robust performance for handling intensive tasks and applications.
Memory: Equipped with 4GB DDR4 ECC SO-DIMM memory, which is expandable up to 32GB. This ensures enhanced multitasking capabilities and system reliability.
Network Ports: Features 4 x RJ-45 1GbE LAN ports, supporting Link Aggregation and Failover. This provides improved network performance and redundancy.
USB Ports: Includes 2 x USB 3.2 Gen 1 ports for connecting external storage devices and peripherals, enhancing the device’s versatility.
eSATA Port: Comes with 1 x eSATA port for additional storage expansion, offering more flexibility in managing your storage needs.
Specification :
| Model | Synology RackStation RS1221+ |
| CPU | |
| CPU Model | AMD Ryzen V1500B |
| CPU Frequency | 4-core 2.2 GHz |
| Hardware Encryption Engine | Yes |
| Memory | |
| System Memory | 4 GB DDR4 ECC SODIMM |
| Memory Module Pre-installed | 4 GB (4 GB x 1) |
| Maximum Memory Capacity | 32 GB (16 GB x 2) |
| Total Memory Slots | 2 |
| Storage | |
| Drive Bays | 8 |
| Maximum Drive Bays with Expansion Unit | 12 (RX418 x 1) |
| Compatible Drive Type | 3.5″ SATA HDD 2.5″ SATA HDD 2.5″ SATA SSD |
| Hot Swappable Drive | Yes |
| External Ports | |
| RJ-45 1GbE LAN Port | 4 (with Link Aggregation / Failover support) |
| USB 3.2 Gen 1 Port | 2 |
| eSATA Port | 1 |
| PCIe | |
| PCIe Expansion | 1 x Gen3 x8 slot (x4 link) |
| File System | |
| Internal Drives | Btrfs EXT4 |
| External Drives | Btrfs EXT4 EXT3 FAT NTFS HFS+ exFAT |
| Others | |
| Form Factor (RU) | 2U |
| System Fan | 80 mm x 80 mm x 2 pcs |
| Fan Speed Mode | Full-Speed Mode Cool Mode Quiet Mode |
| Power Supply Unit / Adapter | 250W |
| Power Consumption | 49.89 watts (Access) 22.64 watts (HDD Hibernation) |
| AC Input Power Voltage | 100 V to 240 V AC |
| Operating Temperature | 0°C to 35°C |
| Storage Temperature | -20°C to 60°C |
| Certifications | FCC, CE, BSMI, EAC, CCC, KC, VCCI, RCM |
| Miscellaneous | |
| Dimensions(Height x Width x Depth) | 88 mm x 482 mm x 306.6 mm |
| Net Weight | 6.9 kg |
| Warranty | 3 Year Brand Warranty |
| Package Contents | Main Unit X 1 Accessory Pack X 1 AC Power Cord X 1 C13 to C14 power cord x 1 Quick Installation Guide X 1 |
