Thermaltake CTE C700 TG ARGB Snow Mid Tower Chassis CA-1X7-00F6WN-01
Overview :
The CTE C700 TG ARGB Snow, a specially designed E-ATX mid tower chassis from the new CTE form factor series, was engineered to provide optimal thermal efficiency to ensure that critical components of your build are provided with adequate cooling. To achieve this the CTE C700 TG ARGB Snow can support up to a 420mm AIO radiator not only at the front but also at the rear of the chassis. Three 140mm CT140 ARGB fans are pre-installed.
Sync with Motherboard RGB Software
Designed to synchronize with ASUS Aura Sync, GIGABYTE RGB Fusion, MSI Mystic Light Sync, and ASRock Polychrome. It supports motherboards with a 5V addressable RGB header, allowing you to control the lights directly from the software mentioned above without installing any extra lighting software or controllers. For more details, please visit ASUS, GIGABYTE, MSI, and ASRock official websites.
Specification :
P/N | CA-1X7-00F6WN-01 |
SERIES | CTE |
CASE TYPE | Mid Tower |
DIMENSION (H X W X D) | 566.5 x 327.6 x 505.5 mm |
(22.3 x 12.9 x 19.9 inch) | |
NET WEIGHT | 15.8 kg / 34.83 lbs. |
SIDE PANEL | 4mm Tempered Glass x 2 |
COLOR | White |
MATERIAL | SPCC / ABS |
COOLING SYSTEM | Front(intake): |
140 x 140 x 25 mm CT140 ARGB white fan (1500rpm, 30.5 dBA) x 1 | |
Top(exhaust): | |
140 x 140 x 25 mm CT140 ARGB white fan (1500rpm, 30.5 dBA) x 1 | |
Rear(intake): | |
140 x 140 x 25 mm CT140 ARGB white fan (1500rpm, 30.5 dBA) x 1 | |
DRIVE BAYS | 7 x 3.5” or 6 x 2.5” |
EXPANSION SLOTS | 7 |
MOTHERBOARDS | 6.7” x 6.7” (Mini ITX), 9.6” x 9.6” (Micro ATX), |
2” x 9.6” (ATX), 12” x 13” (E-ATX) | |
I/O PORT | USB 3.2 (Gen 2) Type-C x 1, USB 3.0 x 2, HD Audio x 1 |
PSU | Standard PS2 PSU (optional) |
FAN SUPPORT | Front: |
3 x 120mm, 2 x 120mm, 1 x 120mm | |
3 x 140mm, 2 x 140mm, 1 x 140mm | |
x 200mm, 1 x 200mm | |
Top: | |
2 x 120mm, 1 x 120mm | |
2 x 140mm, 1 x 140mm | |
Right: | |
1 x 120mm, 1 x 140mm | |
Rear: | |
3 x 120mm, 2 x 120mm, 1 x 120mm | |
3 x 140mm, 2 x 140mm, 1 x 140mm | |
Bottom: | |
3 x 120mm, 2 x 120mm, 1 x 120mm | |
2 x 140mm, 1 x 140mm | |
RADIATOR SUPPORT | |
Front: | |
1 x 360mm, 1 x 240mm, 1 x 120mm | |
1 x 420mm(AIO only), 1 x 280mm, 1 x 140mm | |
Rear: | |
1 x 360mm, 1 x 240mm, 1 x 120mm | |
1 x 420mm(AIO only), 1 x 280mm, 1 x 140mm | |
Bottom: | |
1 x 360mm, 1 x 240mm, 1 x 120mm | |
1 x 280mm, 1 x 140mm | |
CLEARANCE | CPU cooler max height: |
190mm | |
VGA max length: | |
327mm (With radiator) | |
410mm (Without radiator) | |
PSU max length: | |
220mm |
