Asus PN62 Barebone Mini PC PN62-BB5241MV – 90MR00A6-M002F0 (Intel Core i5-10210U Processor)
Overview :
Ultraslim computer with 12th Gen Intel® Core™ processors, fan-less chassis for 15W CPU, 4K triple-display support, dual LAN, dual COM ports, PCIe® Gen 4 SSD, WiFi 6E, 50°C operational ambient temperature
Powered by Intel® 12th Generation Core™ processors
Fan-less design for 15-watt CPU while minimizing noise and dust ingress
4K triple-display support via HDMI with EDID emulation and virtual display
Slim and compact, measuring just 199.7 x 119.7 x 33.9 mm
Comprehensive I/O ports including dual COM, dual LAN with 1x 2.5G and up to five USB ports
Support up to up to 2x M.2 PCIe Gen4x4 SSD
Integrated Wi-Fi 6E and Bluetooth for easy cordless connections
Provide plenty of mounting solution including wall mount, din rail, VESA and rack mount
Support up to 50°C operational ambient temperature
24/7 reliability — Extensively tested to ensure long-term dependability
Specifications
P/N | 90MR00V1-M001M0 |
Model No | PL64-B-S5052MN |
CPU | Intel Core i5-1235U Processor 3.3GHz (12MB Cache, up to 4.4GHz) |
Graphics | Intel® Iris® Xe Graphics or Intel® UHD Graphics for 12th Gen Intel® Processors |
RAM | No |
Storage | No |
Key Board Mouse | No |
Wifi/BT | Wi-Fi 6E, Bluetoothe 5.2, 2*2 (Barebone SKU) |
LAN | 2.5G LAN Intel® I225V and 1G LAN, Intel® I219V |
Side(Front) I/O | 3 x USB 3.2 Gen2, 2 x COM (RJ50; support RS232, 422, 485 ) , 1 x Audio Jack (Line out/ Mic in/ Headphone out), 2 x USB 3.2 Gen1, 1 x Kensington lock |
Back I/O | 3 x HDMI 2.0 Port, 1 x Intel (RJ45) 2.5G LAN, 1 x Intel (RJ45) 1G LAN, 1 x EDID reset , 2 x Antenna Jack, 1 x DC-in |
Vesa Kit | Yes |
Operating System | No |
Warranty | 3 Years/- |
USP | dual LAN Dual COMport-RJ50 3 HDMI 5 USB |
